CLEANROOM DESIGN

Tested cleanroom suitability up to GMP A/B

All HMI of the cleanroom series as well as the corresponding brackets and adapters have been tested by the Fraunhofer Institute.

Frameless design | No joints or cracks

By consistently dispensing with frames and weld seams, our CR series products have a completely smooth and easy-to-clean surface without joints or cracks.

Fully integrated connectivity tools

Wifi, Bluetooth®, power supply unit and reader (RFID / NFC) are completely integrated in the housing of the HMI - without any protruding additional elements. This avoids hygiene and leakage risks that can occur with external connections.

Screwless V4A stainless steel housing

The housings of the CR series are bevelled towards the rear, completely screwless and thus enable convenient and residue-free wiping and/or air cleaning.

High chemical resistance of all materials

The materials used are highly resistant to disinfectants and cleaning agents commonly used in the industry.
Individual tests for special chemical substances are possible in cooperation with the Fraunhofer Institute Stuttgart.

Completely sealed housing (IP69)

The HMI of the CR series are completely closed in accordance with the IP69 standards. They also have a passive cooling system without fans or cooling fins.

IMPLEMENTATION

Diverse mounting options - individual adjustments possible

Our various holding systems enable simple integration of the clean room HMI in cleanrooms up to GMP class A / B.
Whether support arm systems, wall brackets, laboratory stations, ceiling mounts, or complete workstations - we find solutions for optimal implementation in your production environment.



Internal cable management

All cables of the cleanroom HMI can be conveniently connected via the closed holding systems. Peripheral devices can be connected to the cleanroom HMI without cables via Bluetooth®/Wifi as well as wired.

Bayonet system

All mounting systems are compact and space-saving. They also have a bayonet system for quick and easy assembly, which can be carried out by just one person.

GMP A/B certification

Both the laboratory stations and the adapters for wall mounting and connection to support arm systems have - similar to the cleanroom HMI - a certificate from the Fraunhofer Institute for use up to cleanroom class GMP A/B.

Laboratory station
Workstation
Support arms
Wall mounts

CONNECTIVITY

Fully integrated RFID/NFC readers

The cleanroom HMI from CAITRON can be equipped with integrated RFID/NFC modules (125 Khz and 13.56 MHz technologies). This enables seamless integration into cross-device integrated solutions for rights management and access control. Employees log on to the cleanroom HMI contactlessly using an RFID transponder. This means that access authorizations can be linked to existing authentication solutions (e.g. access control, time recording).

All RFID and NFC readers used are integrated directly into the housing of the cleanroom HMI. This means that no additional component is required that has to be introduced into the cleanroom or screwed onto the GMP A/B certified housing.

Integrated Wifi and Bluetooth®

The cleanroom HMIs have fully integrated Wifi and Bluetooth® modules for convenient connection of peripheral systems.

USABILITY

P-CAP Multitouch

The P-CAP Multitouch enables intuitive and convenient operation as you know it from touch pads or smartphones. Drag & drop functions and operation with several fingers at the same time make the use of the cleanroom HMI more effective and easier.

Of course, the P-CAP touches used can also be operated with cleanroom gloves or our cleanroom stylus.

The sensitivity of the P-CAP Multitouch can be easily adjusted to individual requirements using a software tool.



Full HD Displays

Thanks to an additional increase in brilliance by means of optical bonding, the clean room HMIs offer optimal visualization on 17-24 inch full HD widescreen displays.

Multifunction button

The cleanroom PCs can not only be switched on and off using the multifunction button.
It, moreover ist used to call up the CAITRON app, which can be configured completely individually and has a virtual keyboard, brightness control and cleaning mode as standard.

A completely individual programming of the multifunction button can also be implemented at any time.



OPEN PLATFORM

Operating system-independent platform

The CAITRON cleanroom HMI have a completely open platform and can be operated with a variety of operating systems.

These include, among others:

  • Microsoft® Windows®
  • IGEL
  • Linux (SuSe & Ubuntu)
  • Android

PERIPHERALS

Glass and silicone keyboards suitable for cleanrooms

All cleanroom HMIs can be equipped with brackets for glass and silicone keyboards. The keyboards are connected via Bluetooth® or wired, depending on the model.
Individual connections to other keyboards are possible at any time.

Barcode scanners

Brackets for barcode scanners are available for all cleanroom HMIs and are attached directly to the holding system.

Stylus

To operate the P-CAP Touch, cleanroom-compatible styluses with a stainless steel shaft and either a double tip or a holding cable are available.

CAITRON APP

Freely configurable input keys

The CAITRON app has a large number of freely configurable keys to generate shortcuts for keyboard inputs and function commands. This enables quick and easy access to frequently used commands and inputs.

As standard, the program has a NUM block, an ABC keyboard and a calculator. All buttons and commands used for this can also be changed and freely configured using the Admin Tool.



Cleanroom HMI information at a glance

The software tool has an information function with which system information such as serial number, BIOS version, UUID etc. can be called up.

Cleaning mode

The cleaning mode can also be started using the CAITRON app. This deactivates all inputs and thus enables convenient wipe cleaning.

SERVICE CONCEPT

Individual support

Our support ranges from implementation to individual reader adaptation.

Free demo devices

Convince yourself of our products in advance - free of charge and without obligation!

24/7 Service

We prefer direct contact and do not have a call center.
Whether in the middle of the night, on the weekend or on public holidays - our service will be happy to help you personally.

Immediate replacement

In an emergency, we do not hold you back with formalities, but send you a replacement device immediately for the duration of the repair.
